eARC

WELDING
SIMULATOR

Let’s strike an arc!

Learn more Watch demo Booklet
eARC interface unit sketch

One solution — Three welding methods

Key benefits

  • Cost-effective — no metals, gas or electrodes to waste.
  • Eco-friendly — no fumes or pollution.
  • Safe training — no risk of burns or fire.
  • Real experience — arc, light, sound and motion like in reality.
  • Customizable — interface language, package, scenarios.
Training screen sample

Technical specifications

Name of the parameterValue
U0, peak voltage (open circuit)≤ 100 V
Us, average voltage (open circuit)≤ 65 V
I2max, max welding current≤ 4.5 A
U2min…U2max, arc voltage range18…40 V
U1, power supplyAC 220–230 V (50/60 Hz)
P1max, max power consumption≤ 0.250 kW
Arc length measurement0.5…6.5 mm
Travel speed measurement2…15 mm/s
Angles range (MMA)±90°
Angles range (TIG / MIG-MAG)±45°
Continuous arc time≤ 10 minutes
Interface unit weight≤ 9 kg

Demo video

▶ Full HD version

Talk to us

RD WARE sp. z o.o., Warszawa, Polska

Request pricing Back to top
eARC demo photo
